Odstředivé čerpadla IWAKI

Extremely reliable, compact mag. the IWAKI MD series centrifugal pump drive can be used in many applications. There are three main types of pumps between 5 and 135 l/min.

Contamination of the surrounding space with the pumped liquid is prevented thanks to the seal-free construction. Corrosion, which may depend on the pump design, is also not manifested. Therefore, this series is most suitable for installation in machines. The already standard type (polypropylene) offers the best chemical resistance due to the choice of materials used.

Special models are available for high delivery heights (MD-Z) or higher flow rates (MD-X). Economical laying is so possible that the pump performance is the same as the next larger standard type. From pump size MD15, hose or threaded connections are available.

Odstředivé čerpadlo NRD-08 Max. výkon 7,9 l/min, výtlak 11,5 m, el. motor 24V DC 36W

(200 pcs)

Code: NRD-08TV24-REURRD0034

206 €

(249 € incl. VAT)

Centrifugal pump MD-30RM-220N Max. performance 32 l/min, displacement 3.8 m, electricity engine 60 W 230 IN 50 Hz, connection external thread 3/4" BSP

(1 pcs)

Code: MD-30RM-220N

623 €

(754 € incl. VAT)

Centrifugal pump MD-70RZ Max. performance 40 l/min, displacement 14,3 m, electricity engine 245 W 230 IN 50 Hz

Dodací termín 2 až 3 pracovní dny

Code: MD-70RZ 220/240V

1 098 €

(1 329 € incl. VAT)

Centrifugal pump MD-70R Max. performance 86 l/min, displacement 6,7 m, electricity engine 235 W 230 IN 50 Hz

(1 pcs)

Code: MD-70R 220/240V

1 098 €

(1 329 € incl. VAT)

Centrifugal pump MD-55RM Max. performance 60 l/min, displacement 5.6 m, electricity engine 130 W 230 IN 50 Hz

Dodací termín 2 až 3 pracovní dny

Code: MD-55RM 220/240V

872 €

(1 056 € incl. VAT)

Centrifugal pump MD-40RZ-220N Max. performance 22 l/min, displacement 10 m, electricity engine 140 W 230 IN 50 Hz

(1 pcs)

Code: MD-40RZ-220N

834 €

(1 010 € incl. VAT)

Centrifugal pump MD-40R-220N Max. performance 45 l/min, displacement 4.6 m, electricity engine 90 W 230 IN 50 Hz

(1 pcs)

Code: MD-40R-220N

781 €

(945 € incl. VAT)

Centrifugal pump MD-30RZ-220N Max. performance 15 l/min, displacement 8 m, electricity engine 80 W 230 IN 50 Hz

(1 pcs)

Code: MD-30RZ-220N

781 €

(945 € incl. VAT)

Centrifugal pump MD-30R-220N Max. performance 32 l/min, displacement 3.8 m, electricity engine 60 W 230 IN 50 Hz

(2 pcs)

Code: MD-30R-220N

623 €

(754 € incl. VAT)

Centrifugal pump MD-20RZ-220N Max. performance 10 l/min, displacement 4.9 m, electricity engine 40 W 230 IN 50 Hz

(1 pcs)

Code: MD-20RZ-220N

529 €

(640 € incl. VAT)

14 items total

New

Odstředivé čerpadlo NRD-08 Max. výkon 7,9 l/min, výtlak 11,5 m, el. motor 24V DC 36W

(200 pcs)

249 € incl. VAT

206 € / pcs

Centrifugal pump IWAKI MD series with magnetic coupling in plastic design for pumping chemical liquids. Magnetic coupling guarantees drip-free operation. The pump cannot be...

Code: NRD-08TV24-REURRD0034

Centrifugal pump MD-6-230GS01 Max. performance 8 l/min, displacement 1 m, electricity engine 22 kW 230 IN 50 Hz

(6 pcs)

272 € incl. VAT

225 € / pcs

Centrifugal pump IWAKI MD series with magnetic coupling in plastic design for pumping chemical liquids. Magnetic coupling guarantees drip-free operation. The pump cannot be...

Code: MD-6-230GS01

Centrifugal pump MD-10-230GS01 Max. performance 11 l/min, displacement 1.5 m, electricity engine 35W 230 IN 50 Hz

(4 pcs)

289 € incl. VAT

239 € / pcs

Centrifugal pump IWAKI MD series with magnetic coupling in plastic design for pumping chemical liquids. Magnetic coupling guarantees drip-free operation. The pump cannot be...

Code: MD-10-230GS01

Centrifugal pump MD-15R-230GS Max. performance 16 l/min, displacement 2.4 m, electricity engine 26 W 230 IN 50 Hz

(1 pcs)

445 € incl. VAT

368 € / pcs

Centrifugal pump IWAKI MD series with magnetic coupling in plastic design for pumping chemical liquids. Magnetic coupling guarantees drip-free operation. The pump cannot be...

Code: MD-15R-230GS

Centrifugal pump MD-20RM-230N Max. performance 27 l/min, displacement 3.1 m, electricity engine 40 W 230 IN 50 Hz

Dodací termín 2 až 3 pracovní dny

606 € incl. VAT

501 € / pcs

Centrifugal pump IWAKI MD series with magnetic coupling in plastic design for pumping chemical liquids. Magnetic coupling guarantees drip-free operation. The pump cannot be...

Code: MD-20RM-220N

Centrifugal pump MD-20RZ-220N Max. performance 10 l/min, displacement 4.9 m, electricity engine 40 W 230 IN 50 Hz

(1 pcs)

640 € incl. VAT

529 € / pcs

Centrifugal pump IWAKI MD series with magnetic coupling in plastic design for pumping chemical liquids. Magnetic coupling guarantees drip-free operation. The pump cannot be...

Code: MD-20RZ-220N

Centrifugal pump MD-30R-220N Max. performance 32 l/min, displacement 3.8 m, electricity engine 60 W 230 IN 50 Hz

(2 pcs)

754 € incl. VAT

623 € / pcs

Centrifugal pump IWAKI MD series with magnetic coupling in plastic design for pumping chemical liquids. Magnetic coupling guarantees drip-free operation. The pump cannot be...

Code: MD-30R-220N

Centrifugal pump MD-30RM-220N Max. performance 32 l/min, displacement 3.8 m, electricity engine 60 W 230 IN 50 Hz, connection external thread 3/4" BSP

(1 pcs)

754 € incl. VAT

623 € / pcs

Centrifugal pump IWAKI series MD-30RM-220N Max. output 32 l/min, discharge 3.8 m, electric motor 60 W 230 V 50 Hz, connection 3/4" BSP male thread with magnetic coupling in...

Code: MD-30RM-220N

Centrifugal pump MD-30RZ-220N Max. performance 15 l/min, displacement 8 m, electricity engine 80 W 230 IN 50 Hz

(1 pcs)

945 € incl. VAT

781 € / pcs

Centrifugal pump IWAKI MD series with magnetic coupling in plastic design for pumping chemical liquids. Magnetic coupling guarantees drip-free operation. The pump cannot be...

Code: MD-30RZ-220N

Centrifugal pump MD-40R-220N Max. performance 45 l/min, displacement 4.6 m, electricity engine 90 W 230 IN 50 Hz

(1 pcs)

945 € incl. VAT

781 € / pcs

Centrifugal pump IWAKI MD series with magnetic coupling in plastic design for pumping chemical liquids. Magnetic coupling guarantees drip-free operation. The pump cannot be...

Code: MD-40R-220N

Centrifugal pump MD-40RZ-220N Max. performance 22 l/min, displacement 10 m, electricity engine 140 W 230 IN 50 Hz

(1 pcs)

1 010 € incl. VAT

834 € / pcs

Centrifugal pump IWAKI MD series with magnetic coupling in plastic design for pumping chemical liquids. Magnetic coupling guarantees drip-free operation. The pump cannot be...

Code: MD-40RZ-220N

odstredive cerpadlo IWAKI md55 Create Flow

Centrifugal pump MD-55RM Max. performance 60 l/min, displacement 5.6 m, electricity engine 130 W 230 IN 50 Hz

Dodací termín 2 až 3 pracovní dny

1 056 € incl. VAT

872 € / pcs

Centrifugal pump IWAKI MD series with magnetic coupling in plastic design for pumping chemical liquids. Magnetic coupling guarantees drip-free operation. The pump cannot be...

Code: MD-55RM 220/240V

odstredive cerpadlo IWAKI md70 Create Flow

Centrifugal pump MD-70R Max. performance 86 l/min, displacement 6,7 m, electricity engine 235 W 230 IN 50 Hz

(1 pcs)

1 329 € incl. VAT

1 098 € / pcs

Centrifugal pump IWAKI MD series with magnetic coupling in plastic design for pumping chemical liquids. Magnetic coupling guarantees drip-free operation. The pump cannot be...

Code: MD-70R 220/240V

odstredive cerpadlo IWAKI md100 Create Flow

Centrifugal pump MD-70RZ Max. performance 40 l/min, displacement 14,3 m, electricity engine 245 W 230 IN 50 Hz

Dodací termín 2 až 3 pracovní dny

1 329 € incl. VAT

1 098 € / pcs

Centrifugal pump IWAKI MD series with magnetic coupling in plastic design for pumping chemical liquids. Magnetic coupling guarantees drip-free operation. The pump cannot be...

Code: MD-70RZ 220/240V

14 items total
