    Optical sensor with PA cover AO008

    Code: AO008
    Brand: Autosen
    AO008 leaser
    128 € / pcs 155 € incl. VAT 128 € / 1 pcs
    Skladem na externím skladu
    Delivery to:
    26/05/2025
    • Light sensor - receiver
    • Dark switching (normally open)
    • Degree of protection IP67

    Sensor receiver in a cubic construction with a range of 20 m. The remote beam sensor system is characterized by very high detection ranges because it consists of two separate components: a transmitter and a receiver. The automatic AO008 optical receiver reliably switches to a range of up to 20 m. A visible red light allows easy adjustment of the light barrier. The light beam moves in only one direction, thus promoting high resistance to dust, water vapor or lens contamination. This ensures a high operating margin. The AO008 optical receiver can be used with the AO007 optical transmitter.

    Additional technical features and corresponding accessories (sensor cable AA005, AA006, AA007, AA008, attachment AA906 and transmitter AO007)



    Detailed information

    Related products

    AA906 et main 800
    Mounting bracket AA906
    Skladem na externím skladu
    26 € incl. VAT
    21 €

    For safe and optimal sensor installation.

    Code: AA906
    AA037 et main 800 kabel snímače
    Sensor cable 2 m Standard class IP67 AA037
    Skladem na externím skladu
    17 € incl. VAT
    14 €

    Sensor cable with direct connection connector Degree of protection IP 65 | IP67 AC/DC

    Code: AA037
    AA040 et main 800 kabel snímače Create Flow
    Sensor cable 2 m Standard IP class 67 AA040
    Skladem na externím skladu
    18 € incl. VAT
    15 €

    Sensor cable with angled connection Degree of protection IP 65 | IP67 AC/DC

    Code: AA040
    AA947 et main 800 konektor L
    Connector M12 AA947
    Skladem na externím skladu
    22 € incl. VAT
    18 €

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA947
    AA946 et main 800 konektor L
    Connector M12 AA946
    Skladem na externím skladu
    22 € incl. VAT
    18 €

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA946
    AA939 et main 800 Konektor pro kabel senzoru
    Connector M12 AA939
    Skladem na externím skladu
    22 € incl. VAT
    19 €

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA939
    AA921 et main 800 konektor
    Connector M12 AA921
    Skladem na externím skladu
    23 € incl. VAT
    19 €

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA921
    AN001 et main 800
    Single channel switching amplifier AN001
    Skladem na externím skladu
    217 € incl. VAT
    180 €

    The AN001 single channel switching amplifier is used to supply and evaluate sensor signals. It is equipped with a 24 V DC / 300 mA output, a clamp rail housing and is...

    Code: AN001
    AN002 et main 800
    Dual stream management switching amplifiers AN002
    Skladem na externím skladu
    320 € incl. VAT
    265 €

    The two-position control relay has an enclosure with a clamping rail and offers an input delay of 0 ... 10 s. Switching outputs: relay (1 switching contact); Transistor output...

    Code: AN002
    AR003 et main 800
    Monitor speed AR003
    Skladem na externím skladu
    263 € incl. VAT
    217 €

    Position sensors can be combined with the AR003 evaluation system to detect pulses, velocities or stops of non-metallic objects. Intuitive adjustment of pulse count, output...

    Code: AR003
    AO014 Optický snímač s kovovým závitem M18x1
    Optical sensor with metal thread M18x1 AO014
    Skladem na externím skladu
    112 € incl. VAT
    92 €

    Reflective sensor with polarizing filter Visible red light for easy adjustment Dark switching (normally open) Reflective light barrier with polarizing filter, M18x1-metal...

    Code: AO014
    AO002 optický senzor z nerezové oceli
    Optical sensor stainless steel IP69K AO002
    Skladem na externím skladu
    156 € incl. VAT
    129 €

    Reflective sensor with polarizing filter Can be used in hygienic and wet areas High quality compact stainless steel cabinet Best optical performance in standard applications -...

    Code: AO002
    AO020 Mini optický senzor s krytem
    Mini optical sensor with PA cover AO020
    Skladem na externím skladu
    175 € incl. VAT
    145 €

    Visible red light for easy adjustment Diffuse reflection sensor with background suppression Degree of protection IP 65 | IP67 With the AO020 reflective light scanner, the...

    Code: AO020
    AL003 et main 800 Laserový snímač
    Laser distance sensor M30x1,5 metal thread AL003
    Skladem na externím skladu
    319 € incl. VAT
    264 €

    Laser distance sensor with background suppression, M 30x1.5 metal threads, DC PNP, background suppression, visible laser light, laser safety class 2, adjustment, manual...

    Code: AL003
    AO026 optický senzor
    Optical sensor with PA cover AO026
    Skladem na externím skladu
    63 € incl. VAT
    52 €

    Switchable light and dark switching Degree of protection IP 65 | IP67 In combination with the AO027 transmitter The AO026 light sensor features a particularly compact...

    Code: AO026
    AO019 optický senzor s krytem PA
    Mini optical sensor with PA cover AO019
    Skladem na externím skladu
    175 € incl. VAT
    145 €

    Visible red light for easy adjustment Diffuse reflection sensor with background suppression Degree of protection IP 65 | IP67 The AO019 reflected light scanner reliably locates...

    Code: AO019
    Show all related products Previous product Next product

    Product detailed description

    Technical data AO008

    General information

    20 m
    1000 Hz
    receiver
    red light

    Outputs / inputs

    dark
    .

    Electrical data

    Yes
    10 ... 36 V DC power class 2 cULus
    Yes
    Yes
    DC
    PNP
    200 mA
    2.5 V
    II
    10 mA

    Mechanical data

    PMMA
    Polyamide (PA)
    V4A TPE
    gold-plated M12 contacts with 3 pins


    environmental conditions

    . -25°C
    60°C
    IP67

    Further information

    display Switching status: LED, yellow
    DIN EN 60947-5-2
    CE
    cULus
    max. 2 Nm
    1: When using M5 fixing screw

    Additional parameters

    Category: Laserové snímače
    Warranty: 5 let
    Weight: 0.2 kg
