Diaphragm pump ARO 1" Polypropylen/Santoprene, Performance 178 l/min, pressure 8.3 bar Výkon 178 l/min, výtlak 8,3 bar
Code: 6661A3-3EB-CRelated products






        ARO, air service kit, for pump ARO 1" -1 1/2" (PRO)












        Hytrel diaphragm for pump ARO 6605 XXXXX






        Santoprene wheel for pump ARO PD05P, pos. 22












        Service kit for diaphragm pump ARO PD03 contains 2 pcs Teflon diaphragm, 2 pcs Santoprene backing diaphragm, 4 pcs Teflon balls, o-rings






        ARO, valve seat, PP, pos. 21






        ARO, air service kit, PD10. The service kit includes positions 111, 132, 137, 138, 139, 166, 167, 171, 172, 173, 174, 176, 200,












        Santoprene diaphragm for pump ARO PD05P






        Set (4 pcs ) replacement O-rings, pos. 33, 93762 for pump ARO. Item "33" "O" rings are not used on models 66605H-XXX, 66605J-XXX and 66605K-XXX.






        Santoprene diaphragm for pump ARO PD10, pos. 7






        Air service kit for pump ARO PD03/05/07






        Santoprene diaphragm for air control PD10, pos. 176. For the pump it is necessary to use 2 diaphragms.






        ARO, air service kit, PD03/05/07






        Air silencer ARO, pos. 201
Product detailed description





Additional parameters
| Category: | ARO diaphragm pump |
|---|---|
| Warranty: | 1 year |
| Weight: | 9 kg |
| Řada : | ARO |
| Materiál tělesa čerpadla: | Polypropylen |
| Materiál sedel čerpadla: | Polypropylen |
| Materiál kuliček čerpadla: | Santopren |
| Materiál membrán čerpadla: | Santopren |
| Max. výkon: | 178 l/min |
| Max. výtlak: | 8,3 bar |
| pH: | 2 až 14 |
| ? Samonasávací schopnost: | -5,7 m |
| Max. teplota média: | |
| Max. velikost pevných částic: | max. 3,2 mm |
| Připojení sání/výtlak: | Přírubové provedení DN 25 |
| Pohon: | Stlačený vzduch max. 8,3 bar |
| Připojení vzduch: | Vnitřní závit 1/4" |
| ATEX: | NE |






        Plastic diaphragm pump ARO in material version polypropylene, diaphragm and Santoprene beads. Max. pump output Pump material design 465 l/min, max. discharge 8.3 bar. The...
