    Inductive sensor Standard class with 5 m cable IP67 AI901

    Code: AI901
    Brand: Autosen
    AI901 indukční snímač s kabelem main 800
    €35 / pcs €43 incl. VAT
    Skladem na externím skladu
    Delivery to:
    08/05/2024
    • With 5 m PVC cable
    • Degree of protection IP67
    • Thread M8

    Inductive sensor with M8 cylindrical thread and 5m PVC axial lead. The advantage is the small size and robust construction. The nickel-plated brass housing completely protects the sensor from electronic damage and offers protection against mechanical influences according to IP67

    Normally open switching output, PNP output logic and long sensing distance of 2 mm. The inductive proximity switch can be installed in one plane


    Detailed information

    Related products

    AA901 et main 800
    Mounting bracket M8 AA901
    Skladem na externím skladu
    €13 incl. VAT
    €11

    For safe and optimal installation of M8 sensors.

    Code: AA901
    AA947 et main 800 konektor L
    Connector M12 AA947
    Skladem na externím skladu
    €22 incl. VAT
    €18

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA947
    AA946 et main 800 konektor L
    Connector M12 AA946
    Skladem na externím skladu
    €22 incl. VAT
    €18

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA946
    AA939 et main 800 Konektor pro kabel senzoru
    Connector M12 AA939
    Skladem na externím skladu
    €22 incl. VAT
    €18

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA939
    AN001 et main 800
    Single channel switching amplifier AN001
    Skladem na externím skladu
    €216 incl. VAT
    €178

    The AN001 single channel switching amplifier is used to supply and evaluate sensor signals. It is equipped with a 24 V DC / 300 mA output, a clamp rail housing and is...

    Code: AN001
    AN002 et main 800
    Dual stream management switching amplifiers AN002
    Skladem na externím skladu
    €318 incl. VAT
    €263

    The two-position control relay has an enclosure with a clamping rail and offers an input delay of 0 ... 10 s. Switching outputs: relay (1 switching contact); Transistor output...

    Code: AN002
    AR003 et main 800
    Monitor speed AR003
    Skladem na externím skladu
    €261 incl. VAT
    €216

    Position sensors can be combined with the AR003 evaluation system to detect pulses, velocities or stops of non-metallic objects. Intuitive adjustment of pulse count, output...

    Code: AR003
    AA921 et main 800 konektor
    Connector M12 AA921
    Skladem na externím skladu
    €22 incl. VAT
    €18

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA921
    Show all related products Previous product Next product

    Product detailed description

    Technical data AI901

    General information

    mm
    5000 Hz

    Outputs / inputs

    open (NO)
    .

    Electrical data

    Yes
    10 ... 30 V DC
    Yes
    Yes
    DC
    PNP
    200 mA
    1.8 V
    10 mA

    Mechanical data

    PBT
    with thread
    nickel-plated brass
    end
    With 5 m PVC cable
    35,5 mm

    accuracy

    St37 = 1
    Ms approximately 0.5
    Al approx. 0.4
    V2A approx. 0.8
    Cu approx. 0,4
    ... 20% of the actual switching distance Sr

    environmental conditions

    . -25°C
    70°C
    IP67

    Further information

    indicator LED yellow
    fixing nuts
    DIN EN 60947-5-2
    DIN EN 60947-5-2
    CE
    cURus

    Additional parameters

    Category: Indukční snímače
    Warranty: 5 let
    Weight: 0.1 kg
